Rotor Flux Monitoring Services | S5T Service

Rotor Flux Monitoring utilizing advanced flux probes from IRIS Power is the industry-leading solution for diagnosing inter-turn short circuits in generator rotor windings.

Why Rotor Flux Monitoring is Critical?

During operation, the inter-turn insulation of rotor windings can degrade due to thermal stress, high centrifugal forces, or contamination, resulting in shorted turns. If left undetected, this condition can lead to severe operational hazards:

  • Severe Mechanical Vibration: Short circuits disrupt magnetic flux symmetry, generating an Unbalanced Magnetic Pull (UMP) between the rotor and stator, which triggers severe mechanical vibrations.

  • Localized Overheating: To compensate for the loss of magnetic flux, current increases in the non-shorted turns, causing localized hotspots and widespread thermal insulation degradation.

  • Shaft and Bearing Damage: Severe magnetic asymmetry can induce shaft voltages and currents, leading to electrical pitting and premature failure of the bearings.

Key Benefits of IRIS Power Technology

Utilizing IRIS Power’s specialized technology (such as FluxTrac® monitors or Flux Probes) delivers distinct operational advantages:

  • Pinpoint Defect Localization: Accurately identifies the specific rotor slot housing the short circuit and determines the exact number of shorted turns.

  • In-Service (Online) Testing: Enables comprehensive testing while the generator is fully operational and under load—eliminating the need for asset shutdowns or rotor extraction. This allows engineers to track fault behavior dynamically across varying temperatures and power loads.

  • Optimized Maintenance Strategy: Facilitates a seamless transition from traditional scheduled maintenance to proactive Condition-Based Maintenance (CBM). Plant operators can confidently evaluate whether the asset can continue safe operation or strategically schedule repairs during upcoming planned outages instead of facing forced, costly shutdowns.

  • Extended Asset Lifespan: Prevents catastrophic secondary damage caused by severe vibration or rotor-to-stator rubbing resulting from extreme magnetic pull.

S5T Service provides certified diagnostic solutions utilizing genuine IRIS Power instrumentation to guarantee the highest data accuracy and operational reliability for your power generation assets.
